TECHNICAL SPECIFICATIONS

800.1 EVOX – 2Ω
Power @ 12.6V @ 4Ω: 1 X 528 WRMS
Power @ 12.6V @ 2Ω: 1 X 800 WRMS
Power @ 12.6V @ 1Ω: N/A
Power @ 14.4V @ 4Ω: 1 X 589 WRMS
Power @ 14.4V @ 2Ω: 1 X 892 WRMS
Power @ 14.4V @ 1Ω: N/A
Operating Voltage: 8V – 16V
Current Draw (Music): 38 A
Current Draw (Max): 74 A
Recommended Fuse (Music): 40 A
Total Efficiency: 81%
Damping Factor: 200
Frequency Response (-3dB): 5Hz – 500 Hz
SNR: 90dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.1%
Product Dimensions: 5.8 x 4.4 x 1.9 in
Product Dimensions: 14.8 x 11.3 x 5.0 cm

800.1 EVOX – 4Ω
Power @ 12.6V @ 4Ω: 1 X 800 WRMS
Power @ 12.6V @ 2Ω: N/A
Power @ 12.6V @ 1Ω: N/A
Power @ 14.4V @ 4Ω: 1 X 892 WRMS
Power @ 14.4V @ 2Ω: N/A
Power @ 14.4V @ 1Ω: N/A
Operating Voltage: 8V – 16V
Current Draw (Music): 38 A
Current Draw (Max): 74 A
Recommended Fuse (Music): 40 A
Total Efficiency: 80%
Damping Factor: 200
Frequency Response (-3dB): 5Hz – 500 Hz
SNR: 90dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.1%
Product Dimensions: 5.8 x 4.4 x 2.0 in
Product Dimensions: 14.8 x 11.3 x 5.1 cm
